Automatic Glass Bottle steem Capping Machine
Product introduction
It is widely used in automatic vacuum caps for glass bottle iron caps in food and beverage, sauces, Bird's nest , condiments, medicines, health care products and other industries.
Performance characteristics
1. The machine integrates automatic cover, upper cover, steam jet and automatic vacuum cap, which has high production speed, high efficiency and stable and reliable operation.
2, photoelectric sensors, close to the beginning, etc. are all advanced sensory components, to ensure that no bottle does not send cover, card bottle, lack of cover automatic shutdown alarm and other functions, thus ensuring the reliability of the automatic cover;
3. Applicable bottle shape has round, square, various shapes, etc., and has strong applicability;
4. Replace bottles and covers of different specifications with simple adjustment and convenient operation;
5, the use of world-renowned brands of electrical and pneumatic components, low failure rate, stable and reliable performance, long service life.
Technical Parameters
Model: Non-standard customization
Production capacity: 80 ~ 90 bottles / min
Applicable cover type: thread gland
Applicable cover diameter: 38-82mm
Applicable bottle diameter: 30-90mm
Applicable bottle height: 65-260mm
Motor power: 3.12 kw
Steam consumption: 180~230 kg/h
Steam pressure: ≤0.4 MPa
Maximum vacuum: 34~67 KPa
Dimensions: L3000 × W1100 × H2000mm
Equipment weight: about 1100 kg
characteristic
The frame is made of carbon steel, surrounded by stainless steel plate, and the casing is made of thick aluminum plate. The movement is made of stainless steel SUS316L. It is produced by the technology of European White Company. The cover is stable and the pass rate is high. The cap is automatically covered by a cap, and the capper is controlled by a photoelectric switch.
