Name: Bird's Nest Chuck Type Bottle Unscrambling Plug Leak Detection Integrated Machine
Brand: Guanhong
SKU: Guanhong
Price: 18 USD
Availability: InStock
Rating: 4.8 (155 reviews)

Home > products > Capping Sealing Machine >

Bird's Nest Chuck Type Bottle Unscrambling Plug Leak Detection Integrated Machine

Place of Origin:

Guangdong, China

Brand Name:

Guanhong

Request A Quote

Bird's Nest Chuck Type Bottle Unscrambling Plug Leak Detection Integrated Machine

Product Details

Type:

Capping Machine

Applicable Industries:

Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Energy & Mining, Food & Beverage Shops

Showroom Location:

None

Video Outgoing-inspection:

Provided

Machinery Test Report:

Provided

Warranty Of Core Components:

1 Year

Core Components:

PLC, Motor

Application:

Food, Beverage, Commodity, Machinery & Hardware

Driven Type:

Mechanical

Automatic Grade:

Automatic

Packaging Type:

Bottles

Packaging Material:

Plastic, Metal, Glass

Weight:

450 KG

Warranty:

1 Year

Key Selling Points:

High-accuracy

Number Of Downpipes At One Time:

Number Of Stopcocks At One Time::

Number Of Misses At One Time::

Air Pressure:

0.6-0.8Mpa

Voltage:

AC220V/380V 50HZ/60HZ

Suitable Bottle Type:

Customization

Power:

About 6KW

Production Speed:

5000pcs/h

Power Supply:

AC220V, 50HZ.

Material:

The Rack Is Made Of 304# Stainless Steel

Port:

Guangzhou

Payment & Shipping Terms

Minimum Order Quantity

1 set

Price

$18,800.00/pieces 1-4 pieces

Packaging Details

wooden packing

Supply Ability

50 Piece/Pieces per Month

Pneumatic Tire Sealant Bottle Capping Machine with 8 Pairs Wheel Rotation and Sorter

Get Best Price

Packaging Type Wooden Case 900 KG Plastic Round Bottle Capping Machine with Lid Sorter

Get Best Price

High Speed Automatic Vacuum Capping Machine for Glass Bottle Jar Electric Chuck Type

Get Best Price

Single Head PET Bottle Screw Capping Machine for Customer Provided Bottle Samples

Get Best Price

Contact Now

Product Description

Product Overview

can be customized for the food and chemical industry, and the chuck type lid unplug, pressure plug leak detection integrated machine

The machine integrates automatic sorting,arranging, upper cover, automatic screwing cap.It has no bottle to send cover, lack of cover automatic alarm function, high degree of automation.

Automatic capping for plastic/metal round cap, pump caps ,and duckbill caps. Applicable to food,cosmetics,oil, biological,chemical and other industries, play a role in leak-proof ,anti-theft.

Technical Parameters:

1. Number of downpipes at one time: 6 2. Number of stopcocks at one time: 6 3. Number of misses at one time: 6 4. Suitable bottle type: according to customer samples (different bottle types need to change the mold) 5. Downtube form: two sets of manipulators take tubes and insert them into the mold, 6 at a time 8. Lower plug valve form: 1 set of manipulator take 6 plugs and insert them into the valve tube 7. Plug valve form: 6 sets of manipulator independent plug plug 8. Production speed: 5000pcs/h 9. Power: about 6KW 10. Program control: PLC with touch screen man-machine interface 11. Material: The rack is made of 304# stainless steel 12. Air pressure: 0.6-0.8MPa 13.Power supply: AC220V, 50HZ.

Product Paramenters

item	Chuck type lid unplugging leak detection machine
Number of downpipes at one time	6
Number of stopcocks at one time	6
Number of misses at one time	6
Downtube form	1 set of manipulator take 6 plugs and insert them into the valve tube
Lower plug valve form	two sets of manipulators take tubes and insert them into the mold, 6 at a time
Production Speed	5000pcs/h
Power	about 6KW
Materials	The rack is made of 304# stainless steel
Air preesure	0.6-0.8MPa
Power supply	AC220V, 50HZ.

Our Advantages

Guangdong Guanhong Intelligent Equipment Co., Ltd. is a factory that specialized in manufacturing automatic packaging machinery which focus on the research, design, manufacturing and sales. Since its establishment, our company has continuously introduced advanced technology and high-tech technical talents to provide users with tailor-made packaging equipment with professional services and rich experience.
Our company is specialized in: bottle washing machine, drying machine, filling machine, capping sealing machine, labeling machine, filling production line, with excellent cost-effective, unanimously praised by new and old customers.
Ensuring quality, credibility, and enthusiasm service is the purpose of our consistent execution, to provide customers with more customized products and a full range of services. Our long-term pursue is dedicated to improving customer satisfaction and enabling our customers to obtain the best return on investment.

Company Profile

Packaging & Delivery

Customer Photos

FAQ

1: Q: Is your company a factory?

A: Yes, we are a machinery factory that located in Guangzhou, China.

2: Q: Do you have certificates ?

A: Yes. CE, GMP quality.

3: Q: What are the payment methods?

A: T/T, Cash, Western Union is accepted. For regular order, 50% front payment, 50% balance before shiping.

4: Q: What's the lead time ?

A: Usually our delivery time is around 30 to 45 days.

5: Q: Do you support OEM/ODM?

A: Yes, we can accept OEM/ODM.

6: Q: How to pay Express Charge if order samples ?

A: If you have DHL, FEDEX, TNT, UPS account, samples would be sent under freight collected through your account.

If you don't have DHL, FEDEX, TNT, UPS account, we have to calculate freight cost with EXPRESS Company first, before we send the machine, you could pay freight charge directly to our company account.

7: Q: Deliver goods by air or by ship ?

A: Both are okay, you would choose your agent or we would arrange for you.

8: Q: How to visit your factory ?

A: You can visit our factory at work time, just make an appointment with our sales persons. Any more questions, pls feel free to contact us.
