Name: 220V 6 Heads Automatic Piston Toilet Cleaner Bottle Filling Machine with Design
Brand: Guanhong, Guanhong Machinery
SKU: Guanhong, Guanhong Machinery
Price: 19 USD
Availability: InStock
Rating: 4.8 (162 reviews)

Home > products > Bottle Filling Machine >

220V 6 Heads Automatic Piston Toilet Cleaner Bottle Filling Machine with Design

Place of Origin:

Guangdong, China

Brand Name:

Guanhong, Guanhong Machinery

Certification:

GMP

Request A Quote

220V 6 Heads Automatic Piston Toilet Cleaner Bottle Filling Machine with Design

Product Details

Condition:

New

Type:

Filling Machine

Applicable Industries:

Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Retail, Construction Works

Showroom Location:

None

Application:

Beverage, Chemical, Food, Machinery & Hardware, Medical

Packaging Type:

Case

Packaging Material:

Plastic, Wood

Automatic Grade:

Automatic

Driven Type:

Mechanical

Voltage:

220V

Dimension(L*W*H):

2500*1500*2200

Weight:

650KG

Warranty:

1 Year, 1year

Key Selling Points:

Competitive Price

After Warranty Service:

Online Support

Local Service Location:

None

After-sales Service Provided:

Online Support, Engineers Available To Service Machinery Overseas

Product Name:

6 Heads Automatic Piston Bottle Filling Machine

Capacity:

600-3000 Bottles/hour

Filling Accuracy:

±1.0mm

Filling Form:

Piston-type Filling

Irrigation Range:

100~1000ml Or Customer Appoint

Procedure Control:

PLC+ Touch Screen

Conveying Belt Speed:

3m POM Chain Type

Port:

Guangzhou

Payment & Shipping Terms

Minimum Order Quantity

1 set

Price

$19,500.00/pieces 1-1 pieces

Packaging Details

wooden packing

Supply Ability

100 Piece/Pieces per Month

Automatic Edible Oil Cooking Oil Sunflower Coconut Peanut Oil Filling Machine Filler

Get Best Price

Video

Voltage AC220V 50/60HZ Wine Filling Machine Line for Mini Olive Oil Bottling Machine

Get Best Price

Video

Automatic 4 Head Liquid Filling Machine for Packaging Edible Oil/Shampoo/Liquid/Detergent

Get Best Price

Automatic Weighing Filling Machine for Pistachio/Melon Seeds/Potato Chips High Speed

Get Best Price

Contact Now

Product Description

Technical Parameters:
1. Filling the first number: 6
2. Filling capacity: 180ML-330ML
3. Filling the form: quantitative piston long filling
4. Filling speed: 2000 bottles / hour (330 ml bottle calculation)
5. Filling accuracy: ± 1%
6. Material: Filling rack with stainless steel
7. Program control: PLC + touch screen
8. Filling mouth and trough contact with liquid parts
Material: 304 # stainless steel, food grade PVC and POM
9. Pressure: 0.6-0.8MPa
10. Conveyor: 82mm wide POM chain with a speed of 0-15 m / min,
Ground clearance 750mm ± 25mm (according to customer requirements)
11. Conveying motor: 370W frequency control motor
12. Power: about 3KW / 380V three-phase
13. Tank capacity: 100 liters (with level switch).
14. Protection device: Liquid storage tank stop alarm.

220V 6 Heads Automatic Piston Toilet Cleaner Bottle Filling Machine with Design 0

220V 6 Heads Automatic Piston Toilet Cleaner Bottle Filling Machine with Design 1

220V 6 Heads Automatic Piston Toilet Cleaner Bottle Filling Machine with Design 2

220V 6 Heads Automatic Piston Toilet Cleaner Bottle Filling Machine with Design 3

220V 6 Heads Automatic Piston Toilet Cleaner Bottle Filling Machine with Design 4

220V 6 Heads Automatic Piston Toilet Cleaner Bottle Filling Machine with Design 6

220V 6 Heads Automatic Piston Toilet Cleaner Bottle Filling Machine with Design 8

220V 6 Heads Automatic Piston Toilet Cleaner Bottle Filling Machine with Design 10

220V 6 Heads Automatic Piston Toilet Cleaner Bottle Filling Machine with Design 11
