Customizable Automatic Filling Machine Filler for Peanut Butter Soybean Chili Tomato Seafood Sauce Fruit Jam

Place of Origin:

Guangdong, China

Brand Name:

Guanhong

Request A Quote

Customizable Automatic Filling Machine Filler for Peanut Butter Soybean Chili Tomato Seafood Sauce Fruit Jam

Product Details

Condition:

New

Type:

Filling Machine

Machinery Capacity:

1000-6000BPH

Applicable Industries:

Hotels, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Other, Advertising Company

Showroom Location:

None

Application:

Food, Beverage, Commodity, Chemical, Machinery & Hardware, APPAREL

Packaging Type:

Plywood Case

Automatic Grade:

Automatic

Driven Type:

Pneumatic

Voltage:

220V/380V

Weight:

420 KG

Warranty:

1 Year

Key Selling Points:

High-accuracy

Filling Material:

Beer, Water, Oil, Sanitizer, Shampoo, Liquid, Sauce, Peanut Butter

Filling Accuracy:

±1%

Machinery Test Report:

Provided

Video Outgoing-inspection:

Provided

Core Components:

Motor, PLC

Production Capacity:

4, 6, 8, 10, 12, 14, 16 Heads

Filling Method:

Servo Piston Type

Filling Type:

Quantitative Filling

Filling Capacity:

100~500ml,500~1000ml,1000~5000ml

Filling Speed:

About 25-30 Bottles/min (calculated In 500 Ml Bottle)

Can Be Connected With:

Capping Machine, Labeling Machine, Bottle Unscrambler

Air Pressure:

0.6-0.8MPa

Power:

About 4KW/AC220V 50/60HZ

Program Control:

PLC + Touch Screen

After Warranty Service:

Video Technical Support, Online Support

Local Service Location:

None

After-sales Service Provided:

Online Support, Video Technical Support

Marketing Type:

Ordinary Product

Port:

Guangzhou

Payment & Shipping Terms

Minimum Order Quantity

1 set

Price

$10,300.00/pieces >=1 pieces

Packaging Details

Plywood case packing

Delivery Time

30-40 days

Payment Terms

L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability

20 Unit/Units per Month

Automatic Edible Oil Cooking Oil Sunflower Coconut Peanut Oil Filling Machine Filler

Get Best Price

Video

Voltage AC220V 50/60HZ Wine Filling Machine Line for Mini Olive Oil Bottling Machine

Get Best Price

Video

Automatic 4 Head Liquid Filling Machine for Packaging Edible Oil/Shampoo/Liquid/Detergent

Get Best Price

Automatic Weighing Filling Machine for Pistachio/Melon Seeds/Potato Chips High Speed

Get Best Price

Contact Now

Product Description

Product Overview

Automatic honey/peanut butter/shampoo/detergent/oil servo piston filling machine

It is integrated with electrical and pneumatic all together, with PLC touch screen control system, which has a high degree of automation, simple and convenient operation, and high filling accuracy. And with each filling head can be individually controlled to adjust the filling accuracy characteristics, prolong equipment using life and flexibility. This equipment is widely used in food, daily chemical, chemical and Medical industries. Such as: chili sauce, cooking oil, shampoo, lubricants, cough syrup and other products.

Key selling point

1. It adopts integrated-electric touch screen and PLC system control.

2. It is highly automated.

3. It is easy to operate.

4. The filling accuracy is high.

5. Each filling head can separately control the filling accuracy and increase the service life and flexibility.

Product Paramenters

No.	Item	Data
1	Filling form	full servo drive mobile filling
2	Filling heads	4 heads (can be customized)
3	Filling speed	about 25-30 bottles/min (calculated in 500 ml bottle, the actual size and material of the bottle)
4	Filling error	±1%
5	Material	304 stainless steel for filling frame
6	Program control	PLC + touch screen
7	Filling mouth and trough contact liquid parts material	304# stainless steel, food grade PVC
8	Air pressure	0.6-0.8MPa
9	Conveyor belt	82mm wide POM chain belt, speed 0-15 m/min, height 850mm ± 25mm off the ground
10	Conveying motor	370W variable frequency speed regulating motor
11	Power	about 4KW/AC220V 50/60HZ
12	Tank capacity	approx. 200 liters (with level switch)
